E301:
ESWIN Computing E301 32-bit general-purpose processor is a 32-bit RISC-V embedded CPU IP product with low power consumption and ultra-small area.
As the smallest processor in the 3-series ESWIN Computing CPU IP family, E301 supports both machine and user privilege modes, supports standard RISC-V debug, RISC-V CLIC, and optional hardware multiplication and division extensions. làm đại lý And is mainly suitable for small MCU systems that are highly cost sensitive. It is ideal for use in simple, cost-sensitive devices.
As the smallest processor in the 3-series ESWIN Computing CPU IP family, E301 supports both machine and user privilege modes, supports standard RISC-V debug, RISC-V CLIC, and optional hardware multiplication and division extensions. làm đại lý And is mainly suitable for small MCU systems that are highly cost sensitive. It is ideal for use in simple, cost-sensitive devices.
Features
| Features | Description | ||||
| ISA | RISC-V 32-bit EMC_Zicsr_Zifencei | ||||
| Modes | Machine-mode, User-mode | ||||
| Security | PMP Region can optional from 0 to 16 | ||||
| Pipeline | 3-stage pipeline | ||||
| Interrupt | CLIC CLIC interrupt controller, supports up to 32 interrupt requests and non-maskable interrupt(NMI) | ||||
| Debug | Debug module, supports JTAG/cJTAG | ||||
| Bus Interface | Peripheral Port: 32-bit AHB master interface bongda | ||||
| CoreMark（CoreMarks/MHz） | 3.02 | ||||
| Dhrystone-Legal（DMIPS/MHz） | 1.47 | ||||
